LTM4622EY#PBF Explained Simply with Key Specs

The LTM4622EY#PBF is a compact electronic component that engineers use to manage power in devices. It works as a dual output step-down power module. This module supplies two different output voltages from one input source. Many designers choose it for information technology equipment, such as servers or networking devices. Its small size and efficient performance help save space and energy in modern electronics.

Key Takeaways

• The LTM4622EY#PBF is a small, dual output power module that provides two stable voltages from one input, saving space and parts on circuit boards.

• It works efficiently with input voltages from 3.6 to 20 volts and can deliver up to 2.5 amps on each output, making it suitable for many electronic devices.

• High efficiency up to 95% helps reduce heat and energy waste, which keeps devices cooler and extends their lifespan.

• Built-in protection features guard against overcurrent, overheating, and voltage spikes, ensuring reliable and safe operation.

• Its compact size and digital control options make it a cost-effective and smart choice for powering modern IT, industrial, and medical equipment.

LTM4622EY#PBF Overview

Product Type

The LTM4622EY#PBF is a dual output step-down μModule regulator. This means it can take a higher voltage and lower it to two separate, stable voltages. Engineers call this process "buck conversion." The module comes as a complete power solution in a small package. It includes the controller, power switches, inductor, and support components inside one device. This design helps save space on a circuit board. The μModule technology makes it easy to use because most of the hard work is already done inside the module.

Note: μModule regulators like the LTM4622EY#PBF help engineers build reliable power systems faster. They do not need to design every part from scratch.

The LTM4622EY#PBF stands out because it can deliver two outputs at the same time. Each output can be set to a different voltage. This feature is useful when a device needs to power different parts with different voltage levels. The module also works well in systems that need high efficiency and low heat.

Applications

Many designers use the LTM4622EY#PBF in information technology equipment. For example, it powers servers, routers, and storage devices. These products often need stable power for processors, memory, and other parts. The module also fits well in telecom systems, industrial controls, and medical devices.

• Common application areas:

  • Servers and data centers

  • Networking equipment

  • Industrial automation

  • Medical imaging systems

The small size of the LTM4622EY#PBF makes it a good choice for crowded circuit boards. Its dual output feature reduces the number of parts needed. This helps lower costs and makes the design process easier. Many engineers pick this module when they want a simple, reliable, and space-saving power solution.

Specifications

Input Voltage

The LTM4622EY#PBF operates with a recommended input voltage range from 3.6 volts to 20 volts. This range allows the module to work with many common power sources. The device can handle a minimum input voltage of 3.1 volts, but engineers should use 3.6 volts or higher for reliable operation. The absolute maximum input voltage is 22 volts, which should not be exceeded to avoid damage.

• Recommended input voltage: 3.6 V to 20 V

• Minimum input voltage (not recommended): 3.1 V

• Absolute maximum input voltage: 22 V

The input voltage range matches other modules in the same series. Compared to some older modules, the LTM4622EY#PBF supports a lower starting voltage, which gives designers more flexibility.

Output Voltage

The LTM4622EY#PBF provides two adjustable output voltages. Each output can be set anywhere from 0.6 volts to 5.5 volts. This wide range lets engineers power many types of circuits, from low-voltage digital chips to higher-voltage analog parts. The flexibility in output voltage makes the module useful for different applications.

Output Current

Each output channel of the LTM4622EY#PBF can deliver up to 2.5 amps of current. The total output current depends on the input voltage, output voltage, and cooling conditions. Both outputs can supply their rated current at the same time, which helps power multiple loads in one system.

Efficiency

The LTM4622EY#PBF offers high efficiency, which means it converts most of the input power into useful output power. High efficiency reduces wasted energy and lowers heat generation. This helps IT equipment use less electricity and stay cooler. Efficient power modules also help devices last longer by reducing thermal stress.

• Less energy wasted as heat

• Lower operational costs for IT equipment

• Better thermal management

• Longer device lifespan

Package

The module comes in a 25-PowerBBGA surface mount package. Its compact size measures 6.3 mm by 6.3 mm, with a height of 2.4 mm. This small footprint saves space on crowded circuit boards and makes it easy to fit into tight designs.

Temperature Range

The LTM4622EY#PBF works reliably in a wide temperature range. It can operate from -40°C up to +125°C. This range covers most commercial and industrial environments. The device maintains stable performance even in harsh conditions.

• Operating temperature: -40°C to +125°C

Protection Features

The LTM4622EY#PBF includes several built-in protection features to keep systems safe. These features help prevent damage from electrical or thermal problems.

The module protects against input overvoltage, output overcurrent, and overheating. These protections help avoid common failure modes in power supplies. The design also uses a high switching frequency and current mode control. This allows fast response to changes in load or input, keeping the output stable. The integrated package reduces the number of external parts, which lowers the risk of failure.

Tip: Built-in protection features make the LTM4622EY#PBF a reliable choice for critical systems.

LTM4622EY#PBF Benefits

Advantages

The LTM4622EY#PBF offers several important benefits for engineers and designers. Its dual output feature allows one module to power two different circuits at the same time. This reduces the number of parts needed on a circuit board. The compact size helps save space, making it easier to fit into small devices. High efficiency means less energy turns into heat, so devices stay cooler and last longer.

• Dual output channels for flexible power delivery

• Small package saves valuable board space

• High efficiency up to 95% for cooler operation

• Wide input voltage range supports many power sources

• Built-in protection features increase system safety

Note: The module’s wide temperature range makes it reliable in both hot and cold environments. This helps keep equipment running smoothly in many settings.

Comparison

When compared to other step-down power modules, the LTM4622EY#PBF stands out for its unique mix of features. Many similar modules only offer a single output or lack digital control options. The LTM4622EY#PBF supports digital power management, which allows for easier monitoring and control in advanced systems. It also operates at a high switching frequency, which helps reduce the size of other parts needed in the design.

The LTM4622EY#PBF also provides a cost advantage. Its price is much lower than some other modules with similar features. For example, the LTM4644IY#PBF costs over three times as much.

This combination of dual outputs, digital control, high efficiency, and a lower price makes the LTM4622EY#PBF a smart choice for many modern electronic systems.

The LTM4622EY#PBF delivers two stable output voltages from a single input. It features a compact package, high efficiency, and strong protection features. Designers value its dual output and small size for saving space on crowded boards. Many commercial and IT systems benefit from its reliable power delivery.

This module stands out as a smart choice for engineers who need dependable, dual-output power in modern electronics.

FAQ

What does "dual output" mean for the LTM4622EY#PBF?

The module can provide two different output voltages at the same time. Each output works independently. This feature helps power two separate circuits from one device.

Can the LTM4622EY#PBF replace two single-output regulators?

Yes. The LTM4622EY#PBF can take the place of two single-output regulators. This reduces the number of parts on a circuit board and saves space.

How does the module protect against damage?

The LTM4622EY#PBF includes built-in protection. It guards against too much current, high temperature, and voltage spikes. These features help keep devices safe and reliable.

What is the size of the LTM4622EY#PBF?

The small size makes it easy to fit on crowded boards.
